PRODUCT DETAILS
The T0UGHB00K G2 ZONE is the next generation rugged device for mobile workforces. It offers all the benefits of the latest technology, while maintaining important access to legacy systems. All of this, wrapped up in a more flexible, secure and ultimately even more usable device.
KEY FEATURES
- Intel® CoreTM ¡5-10310U vProTM Processor/ intel® CoreTM Ì7-10610U vProTM Processor
- Windows 11 Pro ( Windows10 downgrade preinstalled)
- Next generation IPSa outdoor display technology
- 10.1 " high brightness WUXGA (16:10) display (up to 1000cd/rtf]
- Capacitive 10 finger multi-touchscreen with glove and rain modes
- Digitiser pen
- Tested by an independent third party lab following MIL-STD-B10H
- Water and dust resist [IP65]
- Up to 12 hours battery life
- Configuration Port (serial, LAN, USB 2.0]
- Lightweight design - weights approx. 1,19kg
- The Windows 11 Upgrade timing may vary by device. Features and app availability
- may vary by region. Certain features require specific hardware (see aka.ms/windowsl 1-!
The TOUGHBOOK G2: Customizable, Innovative, Groundbreaking
Today, workers across industries rely on mobile devices to manage the toughest tasks no matter where their work takes them. With this, they need a device that is not only equipped with the latest technology, but one that evolves with the changing needs of the industry they serve. Now, the TOUGHBOOK G2 is here to meet these needs like never before. A new, modular solution with three expansion areas offering 36 different combinations to deliver a cutting-edge user-centric computing application, the TOUGHBOOK G2 offers users increased flexibility and enhanced productivity.
Discover rugged perfection with TOUGHBOOK G2 | Panasonic Toughbook
Discover how, after 25 years of evolution, the TOUGHBOOK G2 is rugged perfection. With configurable gadget interfaces, backwards compatibility and customization capabilities the G2 is as adaptable as it is rugged. To keep mission-critical data secure the Windows 10 Secured-core PC technology provides hardware, firmware, and software protections. The smart card and HF-RFID reader options and quick release SSD help further enhance security.
Evolved to adapt TOUGHBOOK G2 promotion video
Evolved to adapt TOUGHBOOK G2 promotion video
Gregory Bryant, Executive Vice President, Intel Corporation
Gregory Bryant, Executive Vice President, Intel Corporation
Nicole Dezen, VP Device Partner Sales, Microsoft
Nicole Dezen, VP Device Partner Sales, Microsoft
| Mobile Computing Platform | Intel® Core⢠i5-10310U vPro⢠Processor |
| Operating System | Windows 11 Pro |
| RAM | 16GB (max. 32GB) DDR4 |
| Graphic Chip | Intel® UHD Graphics |
| Storage | 512GB OPAL NVMe SSD (1TB optional) with heater |
| LCD | 10.1" Active Matrix (TFT) colour LCD 1920 x 1200 (WUXGA) LCD with sunlight-viewable glove-enabled capacitive touchscreen (up to 1.000cd/m²), IP55 Digitiser |
| Bluetooth⢠| 5.1 + EDR Class 1 |
| Wireless LAN | Intel® Wi-Fi6 AX201 |
| Mobile Broadband* | 4G EM7455 with eSIM support / 5G EM9190 with Stand Alone and eSIM support |
| GPS* | U-Blox NEO-M8N, can not be configured at 5G model |
| Sound | Intel® High Definition Audio subsystem support, Stereo speaker |
| Security | TPM (TCG V2.0 compliant), Integrated hardware security lock slot, Windows Hello compliant Webcam |
| Front Camera | 2 MP with IR / privacy shutter (Windows Hello compliant) |
| Rear Camera | 8mpixel with autofocus and LED flash |
| Rear Expansion Bay Area** | Smart Card Reader, HF-RFID (NFC) Reader |
| Top Expansion Bay Area** | Serial, 2D Barcode Reader, 2nd USB 2.0, 2nd LAN, Thermal by FLIR |
| LAN | x1 Gigabit (2nd LAN optional) |
| USB 3.1 | x1 |
| USB 3.1 type C PD | x1 |
| Headset | x1 |
| DC In | x1 |
| Port Replicator | x1 |
| Dual Antenna Connector | x1 |
| AC Adapter | Input: 100 V - 240 V AC, 50 Hz/ 60 Hz, Output: 15.6 V DC, 7.05 A |
| Battery | Standard: Li-ion 11.4V, 4360mAh Min. (50Whr)Extended: Li-ion 10.8V, 6300mAh Min. (68Whr) |
| Battery Life | Standard: Approx. 12 hours (Mobile Mark⢠2014)Extended: Approx. 18.5 hours (Mobile Mark⢠2014) |
| Power Management | Standby function, ACPI BIOS, Hot swap optional |
| Dimensions (W x H x D) | 279mm x 188mm x 23.5 mm / 11.0â x 7.4â x 0.93â |
| Weight | Approx. 1.19kg / 2.64lb |
| Drop Resistance | MIL-STD 810H, 180cm*** |
| Dust Resistance | IEC529 (JIS C0920) IP6x*** |
| Water Resistance | IEC529 (JIS C0920) IPx5*** |
| Operating Temperature | MIL-STD 810H, -29 °C to 63 °C *** |
| Included in the box | Power Supply, Power Cord, Display cleaning cloth and User Manual |
| * | Optional |
| ** | One option exclusive possible |
| *** | Tested by an independent third party lab following MIL-STD-810H and IEC 60529 |
Image Data
Image Data
Image Data
Image Data
Image Data
Image Data
Image Data
Brochures
toughbook-g2
Brochures
toughbook-g2-1
Case Studies
Dorset & Wiltshire Fire and Rescue Servi...
Case Studies
Dp world improves productivity and servi...
Case Studies
Machine control and Panasonic TOUGHBOOK...
Case Studies
panasonic and safety at bologna airport....
Case Studies
Securely connecting Centrica field engin...
Case Studies
Siemens aims to improve train availabili...
Spec Sheets
toughbook-g2-spece-sheets
The TOUGHBOOK G2: Customizable, Innovative, Groundbreaking
Today, workers across industries rely on mobile devices to manage the toughest tasks no matter where their work takes them. With this, they need a device that is not only equipped with the latest technology, but one that evolves with the changing needs of the industry they serve. Now, the TOUGHBOOK G2 is here to meet these needs like never before. A new, modular solution with three expansion areas offering 36 different combinations to deliver a cutting-edge user-centric computing application, the TOUGHBOOK G2 offers users increased flexibility and enhanced productivity.
Discover rugged perfection with TOUGHBOOK G2 | Panasonic Toughbook
Discover how, after 25 years of evolution, the TOUGHBOOK G2 is rugged perfection. With configurable gadget interfaces, backwards compatibility and customization capabilities the G2 is as adaptable as it is rugged. To keep mission-critical data secure the Windows 10 Secured-core PC technology provides hardware, firmware, and software protections. The smart card and HF-RFID reader options and quick release SSD help further enhance security.
Evolved to adapt TOUGHBOOK G2 promotion video
Evolved to adapt TOUGHBOOK G2 promotion video
Gregory Bryant, Executive Vice President, Intel Corporation
Gregory Bryant, Executive Vice President, Intel Corporation
Nicole Dezen, VP Device Partner Sales, Microsoft
Nicole Dezen, VP Device Partner Sales, Microsoft
| Durability | Fully rugged |
| Ports & Expansions | USB-A x 2 (plus 2 more optional), Thunderbolt™ 4 USB-C (w/PD), MicroS DXC, HDMI (optional 2nd), Optional VGA, Ethernet (optional 2nd), Optional Serial, Audio In/Out, Optional DVD Drive, Optional Blu-ray Drive, Dual SIM (4FF, eSIM) |
Click and go with optional keyboard
Its 2-in-1 detachable keyboard design means your field workers can take the TOUGHBOOK G2 from office (in laptop mode) to their vehicle (in a vehicle dock), then straight into the action (as a tablet).
Rapidly adaptable to any environment
Configurable interfaces (two expansion areas) allow your team to quickly and easily swap in features – from HF-RFID, smartcard and barcode reader, to 2nd LAN port, true serial port, thermal Imaging and additional USB 2.0 port. With 20 possible combinations, it’s always ready, whatever the task.
Backwards compatibility, future expandability
Compatible with most existing accessories and vehicle docks. Add features as your needs change in the future, without having to overhaul your entire TOUGHBOOK ecosystem. Better for ROI, and more sustainable too.
No more device failures, downtime or disturbed work
Engineered from the ground up to be used on-the-go and in harsh environments, tested to military standard (MILSTD810H) and officially IP65-rated for water and dust resistance. The TOUGHBOOK G2 can also survive drops, knocks, vibrations, extreme temperatures and more. And with optional 4G LTE/5G for optimised connectivity, up to 18.5-hour battery life with large battery and optional battery hot-swap for continuous use, your team will always be able communicate, access critical info and report in real time when on the move.
Enterprise security
Microsoft Secured Core-PC technology (across all three Windows products) provides device, identity and data protection at all levels – hardware, firmware and software. The TOUGHBOOK G2’s Windows Hello-capable webcam enables biometric user authentication – while quick-release SDD, and smart card and HF-RFID reader options help further enhance mission-critical data security.
Complementary accessories, vehicle mounts and docks
Rugged and rigorously tested, for maximum convenience and safety out in the field. Built-for-purpose and designed to match the way you work.
