PRODUCT DETAILS
TOUGHBOOK 33 2-IN-1 DETACHABLE, the 12.0°fully rugged notebook with hot swappable twin batteries, detachable keyboard with optional
backlit keys, and highly configurable capabilities brings unrivalled flexibility and performance for mobile business computing, Thanks to the
detachable keyboard design and 6 usage modes, the TOUGHBOOK 33 2-IN-1 DETACHABLE offers the best ofall worlds for mobile workers.
Target industries forthe device include field service workers, maintenance, and Service technicians in utities and telecommunications, 35.
well as government agencies, defence, the police, and other emergency services.
KEY FEATURES
- Intel® Core™ i5-10310U vPro™ processor/ Intel® core™ 17-10810U vPro™ processor
- Windows 11 Pro ( Windows10 downgrade preinstalled)
- Next generation Dual-touch (with digitizer) display with 3:2 aspect ratio
- 12.0" QHD (2160 x1440) anti-reflective high brightness outdoor display (up to 1200cd/m’)
- Capacitive 10 finger multi-touchscreen with glove and rain modes
- Digitiser pen embedded in the tablet part
- Detachable keyboard with various enterprise ports and backlit* keys
- Fully rugged design with Water and dust resistance (IP65]**
- User exchangeable and hot-swappable twin batteries
- Up to 10 hours battery life with standard twin batteries (MobileMark™ 2014)
- Up to 20 hours battery life with extended* twin batteries (MobileMark™ 2014}
- Flexible configuration port and business expansion module
- Vehicle mount* available for both notebook and tablet
- The Windows 11 Upgrade timing may vary by device. Features and app availability may vary by region. Certain features require specific hardware (see aka.ms/windows11-spec).
Standard(s) for safety | UL 121201-Nonincendive Electrical Equipment for Use in Class | and II, Division 2 and Class II, Divisions 1 and 2 Hazardous (Classified) Locations, CSA €22.2 No. 213-17-Nonincendive Electrical Equipment for Use in Class | and II, Division 2 and Class lI, Divisions 1and 2 Hazardous (Classified) Locations |
Mobile Computing Platform | Intel® Core™ i5-10310U vPro™ Processor |
Operating System | Windows 11 Pro / Windows 10 Downgrade Model available |
RAM | Built-in 16GB RAM or built-in 32GB* RAM |
Graphic Chip | Intel® UHD Graphics |
Storage | 512GB OPAL NVMe SSD (1TB optional) |
LCD | 12.0" Active Matrix (TFT) colour LCD 2160 x 1440 (QHD) LCD with sunlight-viewable glove-enabled capacitive touchscreen (up to 1.200cd/m²), IP55 Digitiser |
Bluetooth™ | v5.1; Classic mode/ Low Energy mode, Class 1 |
Wireless LAN | Intel® Wi-Fi6 AX201 |
Mobile Broadband* | 4G LTE, supports 3G |
GPS* | U-Blox NEO-M8N |
LAN | x1 (Tablet)x1 (Keyboard) |
Sound | WAVE and MIDI playback, Intel® High Definition Audio subsystem support |
Security | TPM (TCG V2.0 compliant) Password security (supervisor password, user password, hard disc lock) Integrated hardware security lock slot |
Front Camera | 2 MP |
Rear Camera | 8MP with Autofocus and LED flash |
SD/SDXC Memory Card | x1 (Keyboard) |
Configuration port (Tablet)** | Serial, 2D Barcode Reader, 2nd USB 2.0 |
USB 3.1 | x3 (x1 Tablet, x2 Keyboard) |
USB 3.1 type C PD | x1 |
USB 2.0 | x1 optional (Tablet)**x1 (Keyboard) |
HDMI | x1 (Tablet)x1 (Keyboard) |
VGA | x1 (Keyboard) |
Native Serial Port | x1 optional (Tablet)**x1 (Keyboard) |
Headset | x1 (Tablet)x1 (Keyboard) |
DC In | x2 (Tablet + Keyboard) |
Port Replicator | x1 (Keyboard) |
Dual Antenna Connector | x1 (Keyboard) |
Business Expansion Module** | Smart Card Reader, NFC, Fingerprint Reader |
AC Adapter | Input: 100 V - 240 V AC, 50 Hz/ 60 Hz, Output: 15.6 V DC, 4.06A |
Battery | Standard: x2 Li-Ion (3 cell, 22Whr) |
Battery Life | Standard: Approx. 10 hours (Mobile Mark™ 2014) |
Power Management | Hot swap, Standby function, ACPI BIOS |
Dimensions (WxHxD) | Standard Battery: 313.0 mm × 288.4 mm × 46.1 mm |
Weight | Standard Battery: 2.78kg |
Drop Resistance | MIL-STD810H, 150cm*** (in Tablet mode) / 150cm (in Clamshell mode) |
Dust Resistance | IP6x*** |
Water Resistance | IPx5*** |
Operating Temperature | MIL-STD 810G, -20°C to 60°C *** |
Included in the box | Power Supply, Power Cord and User Manual |
Footnote | *Optional**One option exlusive possible in configuration port / business expansion module***Tested by an independent third party lab following MIL-STD-810G Method 516.5 Procedure IV |

Image Data

Image Data

Image Data

Image Data

Brochures
toughbook-33

Brochures
toughbook-33-1

Case Studies
Dorset & Wiltshire Fire and Rescue Servi...

Case Studies
Dp world improves productivity and servi...

Case Studies
Machine control and Panasonic TOUGHBOOK...

Case Studies
panasonic and safety at bologna airport....

Case Studies
Securely connecting Centrica field engin...

Case Studies
Siemens aims to improve train availabili...

Spec Sheets
toughbook-33-spece-sheets

Introducing the TOUGHBOOK 33
Mobile workers require technology that rises to the occasion and evolves with their needs. Now, this legacy continues with the next generation of the fully rugged 2-in-1 TOUGHBOOK 33, featuring significant enhancements to performance, flexibility, functionality and security.

TOUGHBOOK 33: Water Resistance Test
Panasonic TOUGHBOOK devices keep mobile workers connected in all types of conditions. In keeping with this, the fully rugged 2-in-1 TOUGHBOOK 33 prevents water and other liquids from entering the device at IPX5.

TOUGHBOOK 33: Dust Test
No matter where the job takes you, Panasonic TOUGHBOOK comes along, prepared. See here how the fully rugged 2-in-1 TOUGHBOOK 33 keeps dust out at IP6X.
Durability | Fully rugged |
Ports & Expansions | USB-A x 2 (plus 2 more optional), Thunderbolt™ 4 USB-C (w/PD), MicroS DXC, HDMI (optional 2nd), Optional VGA, Ethernet (optional 2nd), Optional Serial, Audio In/Out, Optional DVD Drive, Optional Blu-ray Drive, Dual SIM (4FF, eSIM) |

Fully rugged. Always ready.
Engineered from the ground up to be used on-the-go and in harsh environments, tested to military standards (MILSTD810G) and officially IP65-rated for water and dust resistance. The TOUGHBOOK 33 can also survive drops, knocks, vibrations, extreme temperatures and more. So your team is always ready. No more device failures. No more downtime. No more disturbed work.

A better view
When you’re regularly rotating between indoors and out, night and day, good and bad weather, your screen needs to respond seamlessly.
With a 12” QHD display, the TOUGHBOOK 33 provides clear images in both bright sunlight and dim settings, and although toughened, it’s responsive to finger, glove and pen (even in wet conditions.)
It also has a 3:2 aspect ratio. This taller screen shows more words, spreadsheets, engineering drawings, code and business apps. Less squinting, scrolling and switching – more productivity.

Take it anywhere. For as long as you need.
There’s 4G LTE for optimised connectivity and more than a day of battery life (20 hours) with hot-swap options. The TOUGHBOOK 33 is slim, lightweight and easy to carry, and can be easily integrated into vehicles. So, your team can always communicate, access critical info and report in real time when on the move.

An intuitive, multitasking tool
The TOUGHBOOK 33 comes with multiple configuration and customisation options to fit the way you work. From front and rear cameras, a loud stereo speaker for ease of communication over sirens, and enhanced voice recognition while driving, to a dedicated GPS, backlit keyboard and smartcard and fingerprint readers.

Complementary accessories, vehicle mounts and docks
Rugged and rigorously tested, for maximum convenience and safety out in the field. Built-for-purpose and designed to match the way you work.
Realise the true potential of your devices today. Explore TOUGHBOOK accessories and vehicle mounts here.
